Lithium Battery ER34615

Introduction The Lithium Battery ER34615 utilizes lithium atoms as its main raw material, which exhibits remarkable voltage stability and performs exceptionally well across a wide temperature range. This battery surpasses ordinary batteries in terms of performance characteristics. Moreover, it...

Send Inquiry

Description

Introduction

The Lithium Battery ER34615 utilizes lithium atoms as its main raw material, which exhibits remarkable voltage stability and performs exceptionally well across a wide temperature range. This battery surpasses ordinary batteries in terms of performance characteristics. Moreover, it boasts a high power density and has the ability to store a significant amount of energy. Additionally, this battery demonstrates a prolonged service life of approximately 3-5 years, although its duration may decrease with elevated environmental temperatures. Notably, its self-discharge rate is exceptionally low, resulting in minimal energy consumption. Furthermore, it exhibits impressive tolerance to high temperatures and can consistently operate within a wide range of -55°C to +85°C. As a result, our Lithium Battery ER34615 finds extensive applications in various fields, including the military, medical industry, security monitoring, and the Internet of Things. It is ideal for providing stable and reliable power support to portable medical instruments, electronic locks, smart water meters, and other equipment.

Advantage

This battery boasts remarkable advantages that make it a superior choice. Let's start with its high energy density, allowing it to deliver long-lasting power and minimizing the need for frequent battery replacements. This feature renders it ideal for power-intensive applications like continuous running measuring instruments and wireless sensors. Furthermore, the Lithium Battery ER34615 exhibits an extended service life thanks to its low self-discharge rate. Even after prolonged periods of inactivity, the battery retains a substantial amount of power and delivers it reliably when required. Alongside this, its exceptional stability enables safe operation in extremely high or low temperature environments, while also effectively enduring vibrations and impacts. What sets this battery apart is its compact size, lightweight nature, and portability, making it an excellent fit for portable and remote devices. Whether it's GPS devices, drones, or outdoor electronic devices, this battery provides the necessary energy efficiently. Notably, it's an advanced battery that combines high energy density, long lifespan, stability, and resistance to vibrations, catering to a wide range of applications.

Electrical Characteristics

Model	ER34615
Nominal voltage	3.6V
Nominal capacity	The capacity of a 19000mAh cell is dependent on various factors such as current drain, temperature, and cut off. However, at 2mA and a temperature of 20°C, the cell is capable of storing 19000mAh with a cut off voltage of 2.0V. It should be noted that the restored capacity of the cell will be different depending on the aforementioned factors.
Max.continuous current	230mA
Max. pulse current	Reading voltage requires a peak current of up to 400mA, delivered in pulses lasting 0.1 seconds. The cells must be fully charged and have a base current of 10μA to yield readings above 3.0 volts. The pulses must be applied every two minutes at a temperature of +20.
Operating temperature range	-60℃~+85℃
Weight	Approx. 107g
Storage temperature	Max. 30℃
Shape	D
Dimension(max.)	34.061.5mm(DiameterHeight)
Battery type	Bobbin Type
Electrolyte/Chemistry	Lithium Thionyl Chloride(Li-SOCl2)
Brand	Ruizhi, Beleader, OEM acceptable
Equivalent	LS33600; TL-5930; TL2300; TL4930; TL5930; LS-33600; LS-33600C; SL-780; SB-D01; XL-200F, XL-205F;ER20; ER32L615.
